Jetway HBJC923R3328DG2NL (ARM Cortex A17)

Jetway HBJC923R3328DG2NL (ARM Cortex A17)

  • Rockchip® A53 RK3328 Quad-core 1.5GHz
  • Onboard 1333 /2GB DDR3L DRAM Max. 4GB
  • 8G Flash ROM Max 32GB
  • HBJC923R3328DG2NS: Support 1* GbE and 1* USB3.0
  • HBJC923R3328DG2NL: Support 1* GbE and 1* 10/100M LAN
  • Support 1* Micro SD Socket (Max 64G)
  • 2* USB2.0, 1* OTG/DC-in, 1* HDMI, 1* Line-out
  • 5V DC-in


Share

189.95 EUR
incl. 19% VAT, plus shipping
Available in 3 weeks
Add to cart
MB Model – JR3328-DG2N (1.8” SBC)
 – JR3328-DG2NL (1.8” SBC)
Part No – HBJC923R3328DG2NS
 – HBJC923R3328DG2NL
CPU/Chipset – Rockchip® ARM Cortex A53 RK3328 Quad‐core 1.5GHz SoC Processor
Memory – 2GB/1333MHz DDR3L (Max 4GB)
Storage – 8GB Flash (Max 32GB)
Network – 1 * Realtek RTL8211F-CG / 10/100/1000Mbps – 1 * 10/100 Mbps internal FE PHY
– 1 * Realtek RTL8211F-CG / 10/100/1000Mbps
Rear I/O – 1* RJ45
– 1* USB3.0
– 2* USB2.0 		– 2* RJ45
– 2* USB2.0
Side I/O – 1* HDMI (3840 x 2160@60Hz)
– 1* OTG/5V DC-in
– 1* Audio Line-out
– 1* Micro SD card socket
Power Source – DC 5V-3.0A
– AC 100~240V input
Compliance – RoHS, CE, FCC, CE-LVD
Temperature – Operating temperature: -10 ~ 60° C
– Storage Temperature: -20 ~ 65° C
Dimensions – 94.4 (W) x 60.5 (D) x 33.6 (H) mm
– With Shelf: 110.0 (W) x 111.1 (D) x 33.6 (H) mm
OS Support – Android 7.1
Warranty – 1 Year limited warranty
Life Cycle – Till 2022 Q1
Data sheet Download (PDF)
Data sheet Print view
